T077 Zoomable LED Track spotlight
1)CT02 track light can adjust from 10 to 60 Degree be free by revolve the head of the lamp body(Zoomble lens) which makes this light more flexible for more choice.
1)Dimming：10%~100% brightness dimming, and 2700K WW to 6000K CW adjustable for kinds of scenes.
2)Dimming way: Tuya zigbee dimming, Dali dimming, 0~10V dimming etc for choose.
3)Stable led driver and Aluminum body profile and heat sink to extending the life span of lamps.
4)With high efficiency brand LED chip (Ra>90) for better lighting effect.
5)LED chips be painted with thermal grease with 5.0W/mK heat-conductivity to ensure a stable thermal conductivity.
6)Attenuated 10% during 3 years (Light on 13h/day)
7)355° rotation make the direction movement no limited , it’s suitable for any kind of decoration .
8)Black or white finish color for choose, customize gray/silvery and other colors be available.
Specifications
| Name | LED Track Light | |
| Supplier | LEDEAST | |
| Model | TLZ071 | T077-07 |
| Picture |  |
 |
| Power | COB Max 8W Ra > 90 | |
| CCT | 2700K / 3000K / 3500K / 4000K / 5000K / 6500K / 20000K | |
| Adapter | Customizable: 2-wire / 3-wire / 4-wire(3-Phase) track light adapter (or power driver box), and surface-mounted-base. |
|
| Beam Angle | 6-60º Zoomable | |
| Finish Color | Black / White | |
| Lumen Efficiency | 70-110 lm / w | |
| Main Material | High Quality Aluminum | |
| Heat Dissipating | Behind the COB chip, there is painted with thermal grease with 5.0W/mK heat-conductivity, guarantee a stable thermal conductivity. |
|
| Light Attenuation | Attenuated 10% during 3 years (Light on 13h/day) | |
| Failure Rate | Failure Rate < 2% during 3 years | |
| Input Voltage | AC220V, Customizable AC100-240V | |
| Other | Brand LOGO on the product can be specified. Normally, the product is NON-Dimming version. Customizable: 0-10V (1-10V) / Dali / TRIAC / App Smart / ZigBee / 2.4G Remote Dimming (or Dimming & CCT Adjustable) |
|
| Warranty | 3 Years | |
Application
Usually, LED Track Light be used in where need to be important display, or focus on the display area which you want to pointed, and the light will be on the object or area, or something else and in high lighted like famous paintings and antiques. The focusing design greatly reduces the inventory cost for the user.
But T077 zoomable led track light only 8W and min beam angle is 6 degree, it’s more suitable to light up the small size object like jewelry, shoes and hats, handbags, wine & food, brand logo etc, rather than murals and artworks in big size.
Customization
1)Firstly, the same lamp body can match with different power adapter to suit your track lines, it’s to say, single phase 2wires adapter for 2wires track rail, 3phase 4wires track adapter for 4wires track, ceiling panel for wall-mounted installation way.
2)Second, Buyers can decide whether to use single dimming(only adjust the brightness) or Dual-color dimming( adjust the brightness and CCT together) of knob dimming switch according to their own needs. Obviously, the cost of dual-dimming lamp be higher.
3)DALI dimming, 0-10V / 1-10V dimming,Bluetooth dimming, Tuya Zigbee smart dimming, mijia dimming for the same lamp body also be available for us.
4)Laser marking with your brand or logo on lamps be available.
Welcome share your any special ideas with us, LEDEAST will make it be true.
Installation
LEDEAST’s track spotlight not only can be fix on 100~240Vac track bar(2 / 3 / 4 / 6 wires) , also be match with round ceiling panel for ceiling or wall.
Besides, the same lamp also be suitable for our Multi-function Magnetic track light system for 48V safe voltage, through change a power adapter. Magnet track lighting also is the market trend start from 2019, be more and more popular for modern offices and residential areas with minimalist decoration style.
