W323 Family LED wall washer lights

Short Description:

This LEDEAST  W323 Family uses narrow beam angle of the LED wall washer light allows for focused and directional illumination, enabling precise highlighting of specific architectural or design elements on the wall. It provides enhanced visual impact and accentuates the desired areas.

For W323 series downlight, 0-10V/DALI/TRIAC/2.4G Remote/ZigBee/Bluetooth/APP SMART CW dimming are all available.


Product Detail

Product Tags

zigbee led downlight
Low voltage LED ceiling light

Specifications

We also offer different styles and sizes that can be safely used in a variety of indoor scenarios to suit your different needs

Name LED ceiling light
Supplier LEDEAST
Model W323
Power COB 7W COB 12W COB 20W
Hole size Ø55mm Ø75mm Ø95mm
Size Ø62*79mm Ø84*100.5mm Ø110*121.5mm
Lumen Efficiency 80-110Lm / W
CRI Ra>90
Beam Angle 15°/24°/38°
CCT 2700 / 3000K / 4000K / 5000K / 6500K
Main Material High Quality Aluminum
Heat Dissipating Behind the COB chip, there is painted with thermal grease with 5.0W/mK
heat-conductivity, guarantee a stable thermal conductivity.
Failure Rate Failure Rate < 2% during 3 years
Input Voltage AC220V, Customizable AC100-240V
Other Brand LOGO on the product can be specified.
Normally, the product is NON-Dimming version.
Customizable: 0-10V (1-10V) / Dali / TRIAC / App Smart / ZigBee /
2.4G Remote Dimming (or Dimming & CCT Adjustable)
Warranty 3 Years

Application

W323 Family narrow beam angle of the LED wall washer light allows for focused and directional illumination, enabling precise highlighting of specific architectural or design elements on the wall. It provides enhanced visual impact and accentuates the desired areas.

First, LEDEAST V323 Family LED wall washer lights are ideal for showcasing products and specific areas in commercial settings, attracting attention and engaging customers.

Second,The deep cup design helps to minimize glare and unwanted reflections. By directing the light beam towards the wall surface and preventing excessive light spillage, it creates a more comfortable and visually pleasing environment.

Finally,LEDEAST V323 Family LED wall washer lights are suitable for architectural façade lighting, landscape lighting, commercial displays, stage lighting, interior decoration, art exhibitions, and lighting effect walls. They provide unique lighting effects and visual experiences, enhancing the aesthetic appeal and attractiveness of the space

case of retails



Other

With many years of experience in the development and manufacture of general lighting have made LEDEAST technology one of the most significant innovation and technology drivers in China.

With its solid platform of experience and know-how, LEDEAST technology is not only a manufacturer of lamps but also as a reliable partner for LED technologies in a wide range of lighting applications.

Our main products covers indoor spotlights, track systems, indoor recessed fixtures, indoor recessed fixtures, indoor wall-mounted and wall-recessed luminaries, par Lights, panel Light, Bulbs, LED Strip, LED high bay light, LED flood light, LED canopy light, LED grow light etc.

You can trust for superior quality, innovative technology and superlative service. With me, with light!
