T088 LED Museum Track light
1)COB LED Chip: famous brand OSRAM / CREE / TOYONIA for choose (CRI/ Ra: 90+)
2)LED Driver: Isolated Power Supply (PF>0.9) (Fliker-Free)
3)A series have 10W & 15W & 25W for choose, energy saving over 50%
4)Rotatable through 355°on adapter, 90°adjustable in vertical
5)Deep anti-dazzle zoom lens: adjust the beam angle from 10 degree to 60 degree be freely by O-ring
6)Local knob dimming: Single brightness dimming or brightness and CCT adjustable, switch on the led driver box.
7)Heat-dissipating: High quality 6063 Aluminum lamp body and hollow out design back cover
8)Track adapter: 2wires/3wires/4wires(3phase)and wall-mounted type.
Specifications
|
Name |
LED Track Light |
||
|
Supplier |
LEDEAST |
||
|
Model |
T088-10 |
T088-15 / T088-20 |
T088-25 |
|
Picture |
|
|
|
|
Power |
COB 10W Ra90+ |
COB 15 / 20W Ra90+ |
COB 25W Ra90+ |
|
CCT |
2700K / 3000K / 3500K / 4000K / 5000K / 6500K / 20000K |
||
|
Adapter |
Customizable: 2-wire / 3-wire / 4-wire(3-Phase) track light adapter |
||
|
Beam Angle |
10-60º Zoomable |
||
|
Finish Color |
Black / White |
||
|
Lumen Efficiency |
70-110 lm / w |
||
|
Main Material |
High Quality Aluminum |
||
|
Heat Dissipating |
Behind the COB chip, there is painted with thermal grease with 5.0W/mK |
||
|
Light Attenuation |
Attenuated 10% during 3 years (Light on 13h/day) |
||
|
Failure Rate |
Failure Rate < 2% during 3 years |
||
|
Input Voltage |
AC220V, Customizable AC100-240V |
||
|
Other |
Brand LOGO on the product can be specified. |
||
|
Warranty |
3 Years |
||
Application
LEDEAST’s T088 series zoomable led track light has a simple and generous appearance, but can adjust the beam angle from 10 degree to 60degree be freely according to the object what should be displayed. It’s to say, Zoomable tracklight offers high flexibility of illuminating the objects in a diversified and best effect, help our distributors reduce the inventory greatly to save money.
Obviously, T088 zoomable track light not only be suitable as museum lighting, also be helpful for art galleries, private clubs, villas and Luxury stores etc.
Customization
1)Firstly, the same lamp body can match with different power adapter to suit your 2/3/4/6wires track lines on the ceiling, of course, wall-mounted installation way also be workable.
2)Second, Buyers can decide whether to use single dimming(only adjust the brightness) or Dual-color dimming( adjust the brightness and CCT together) of knob dimming switch according to their own needs. Obviously, the cost of dual-dimming lamp be higher.
3)DALI dimming, 0-10V/ 1-10V dimming,Bluetooth dimming,2.4G, Tuya Zigbee smart dimming, Mijia dimming for the same lamp body also be available for us.
4)Free laser marking with buyer’s brand or logo on lamps be available.
LEDEAST’s a professional manufacturer and supplier on the commercial lighting area more than 10years, we would like to provide with OEM & ODM service for all over the world. Any special requirements, don’t hesitate tell us, LEDEAST will try our best to make it be true.
Installation
Usually, this T088 LED Museum spotlight will be equipped with a 3phase 4wires track adapter to match with 4wires track rail bar for AC 100~240V, also could configure track head of other installation methods such as 2wires, 3wires and wall-mounted panel to fixed on the ceiling or wall..
